2 Megapixel VGA Camera USB Microscope with 6" Display



$185.00

repair tools

Many In Stock


2 Megapixel VGA Camera USB Microscope with 6" Display

The microscope realized Full HD, high object distance, multi-function, multi-output at the same time, and it is enough to meet many different requirements in many industries, such as industrial overhaul, repairing pcb board and teaching demonstration. And it’s appearance design combines more ergonomic consideration, provides users better experience. We sincerely wish this product can release your eyes and improve your work quality. Thanks for your support.

Product Parameters:

  • Model: Camera with USB VGA two output
  • Sensor: 1/3 inch 2MP
  • Effective Pixels: 1600H*1200V
  • VGA Image resolution: 800X600 60Hz,1024X768 60Hz,1280X1024 60Hz,1366X768 60Hz
  • 1440X900 60Hz,1600X1200 60Hz,1920X1080 60Hz
  • Data Bits: 8bit
  • pixel size: 2.8μm*2.8μm
  • Frame rate: 15-45F/S 15fps@1600*1200, 30fps@1024*768,45fps@800*600
  • Definition: 800TV lines
  • Scanning mode: Advance gradually
  • Shutter Type: Electronic Shutter
  • Dynamic Range: 63dB
  • Signal-to-noise ratio: 44dB
  • Sensitivity: 1.0 V/lux-sec (550nm)
  • Exposure time: 10μs–60ms,automatic exposure
  • White balance: AUTO
  • Lens Mount: C/CS
  • Menu features: Brightness, contrast, color saturation, brightness, exposure, automatic exposure, vertical mirror, horizontal mirror, Ink, freezer, negative, black and white, the number of cross line (4), line color
  • OSD: English/Chinese

C-MOUNT Lens:

  • Working distance: 100mm
  • Zoom c-mount Lens
  • 1.0X C-mount adapter
  • Zoom ratios:
  • Objective Magnification Power by 0.7 - 4.5X(about 10 - 200X on the display)
  • Size: 24.5mm(L) * 50mm(DIA)

Package including:

  1. 1 x Digitital Microscope
  2. 1 x Metal holder with LED
  3. 1 x USB cable
  4. 1 x HDMI cable
  5. 1 x 6" LCD display
  6. 1 x Specification
